Technical Specifications |
|
|
Model: |
YP-S650 |
|
Power: |
650W |
|
Power range: |
1%~100% |
|
Processing capacity: |
0.5~500ml |
|
With digital intelligent ultrasonic generator: |
Frequency automatic search |
|
Resonant frequency: |
Real-time tracking and display |
|
Frequency tracking accuracy: |
1Hz Real-time tracking and display |
|
Electric lift soundproof box: |
The workbench adopts electric lift and lighting device |
|
Display method: |
7-inch TFT color screen |
|
Frequency range: |
18~25KHz |
|
Total time range: |
00:00:01~999:99:99 (hours: minutes: seconds) |
|
Output time: |
0.1~99.9 (seconds) |
|
Gap time: |
0.1~99.9 (seconds) |
|
Output duty cycle: |
0.1~99.9% |
|
Over-temperature protection for materials: |
1. Temperature setting: 0-99℃
2. When the material temperature reaches the set value, the ultrasound will stop working, and when the material temperature is 2℃ lower than the set value, the ultrasound will automatically resume working. |
|
Storage documents: |
99 groups |
|
Random amplitude bar: |
Φ6 |
|
Optional amplitude bar: |
Φ2 / Φ3 / Φ10 |
|
Protection alarm: |
Over-temperature, over-current, overload, transducer abnormality, etc. |
|
Power supply: |
AC110/220V F50/60Hz |
|
Overall dimensions: |
280*280*495 |
|
Overall weight: |
12.4KG |
|
Main unit + transducer weight: |
15.0kg |
|
External packaging dimensions: |
534*295*435mm |
